Sheffield Research

Multimeter, Manual Range

Part No.: CT8017

|

SKU: SHECT8017

Colour, sizing or style depicted in some photos may not be exactly as described.
Please check your product description carefully before placing your order.

$77.96

In Stock

ToolDiscounter.com Ratings on Shopper Approved

Customer Reviews

Description

Autorange Digital Multimeter
  • State of the Art ergonomic design and styling for easier handling and use.
  • Full auto ranging range selection.
  • Manual range selection function.
  • Large 3 1/2 digit LCD display with analog bar graph.
  • AC/DC Voltage measurement up to 600 Volt.
  • Manual or automatic VDC/VAC selection.
  • DC current measurement up to 10 A.
  • Resistance measurements up to 32 MOHM.
  • Display data hold.
  • Continuity Test.
  • Diode test.
  • Overload protection.
  • Soft holster for instrument protection.
  • Auto power off.
  • Power source: Two Standard 1.5 Volt alkaline battery type AA UM3 or equivalent.

  • Test probes: One red and one black, 1000V/15A rated (IEC1010/EN61010 CAT II), 35.5 inches long.
  • Physical dimensions: 5.51 x 2.75 x 1.41 inches (140 mm x 70 mm x 36)
  • Weight: Approximately 12.34 ounces (350 g) including battery
    Applications
  • Measure output in sensors like oxygen (O2), coolant temperature, throttle position (TPS), manifold air, pressure (MAP) manifold air flow (MAF), etc.
  • Check grounds, Voltage drops and continuity across Connectors, Wires, Cables, Relays Contacts, Lamps, Switches, etc.
  • Check components like Alternator, Diodes, Relays Coils, Condensers, Ignition Coils, Spark Plug Wires, Magnetic Pick-ups, Motors, Switches, Fuses, etc.
  • An essential tool for all around troubleshooting of electrical and electronic circuit and systems.
    Ergonomic Features:
  • The new smaller and ergonomic profile compared with other models makes handling and operation easier and more convenient.
  • Large easy to read 7/16 inch (11 mm) digits display.
  • Analog bar graph display.
  • Single knob selects function.
  • Range hold function.
  • Rugged plastic enclosure.
  • Rugged plastic enclosure.
  • Soft anti-slip rubber holster protects the instrument against impacts and chemicals.
  • Design allows comfortable hand holding or resting at convenient places horizontally or at an angle by using the stand at the back of the holster.
    For use in: Electronic and electrical circuits, Automobiles, Trucks, Trailers, Boats, RVs, All 0 to 6000 Volt AC/DC powered circuits.
    General Specifications:
  • 3.5 Digit LCD (Max reading 3999)
  • 7/16 inch(11 mm) Digits
  • 32 segments bar graph display.
  • Display data hold indicator.
  • Manual range indicator.
  • VDC/VAC indicator.
  • Automatic over-range indication.
  • Automatic(-) negative polarity indicator.
  • Automatic Zeroing.
  • Low battery indicator.
    Electrical Specifications:
    DC Voltage: ±0.8 percent ± 2 dgts., 2MOhm input impedance, 600 V ac/dc Overload protection.
    AC Voltage: ±1.2 percent ± 5 dgts., 2MOhm input impedance, 50 to 200 Hz, 600 V ac/dc Overload protection.
    DC Current: ± 1.5 percent ± 2 dgts., Internal 200mA/10A 250V fuse protection.
    AC Current: ± 1.5 percent ± 5 dgts., Internal 200mA/10A 250V fuse protection.
    Resistance: ±1.2 percent ± 3 dgts., 250 V ac/dc Overload protection.
    Diode test: 1.0 ± 0.6 mA test current, 3.2 V max. test voltage.
    Continuity Test: Audible indicator (Buzzer) with circuit resistance is below 18 Ohm.
