Samson

Heavy Duty Hose Reel

Part No.: 508225

|

SKU: SAM508225

Shipping Calculated at Checkout
  • Samson 508225 Heavy Duty Hose Reel

Color, sizing or style depicted in some photos may not be exactly as described.
Please check your product description carefully before placing your order.

$2,097.86

Ships in 7-10 days

Description

  • Long-life heavy duty design. Double arm full metal design provides the robustness and strength required to stand the most demanding environments. Heavy gauge steel welded base and epoxy powder coated finishing for longer durability
  • Bearing mounted spool. The spool is mounted on two permanently lubricated and sealed ball bearings. Minimum friction to reduce torque load on power spring for smooth retraction and durability
  • Full port design. Real 1" port, no flow restrictions in shaft and swivel
  • Optimized power spring life and performance. High fatigue resistance spring for a long, trouble free life. Optimized strength for an easy hose pull out, especially those last feet
  • No lockout design. Ratchet is never locked when the hose is fully extended in every mounting position
  • Easy installation and maintenance. Outlet arm can be placed in 6 positions for optimum installation. Hose reel maintenance can be easily performed without dismounting the reel from its position
  • Narrow design. More reels fit in a smaller surface
  • Zinc plated steel rollers. Extra strength and durable outlet for longer life

Specifications

Application

Medium pressure lubricants

Delivery Hose

1" NPT (M) 1

Operating Temperature

14 to 140°F (-10 to 60°C)

Bearings

Sealed ball bearings

Weight With No Hose

88 lbs. (40 kg)

Hose ID

1/2"

Outlet Thread

1/2" NPTM

Inlet Thtread

1/2" NPTF

Hose Working Pressure

1500 PSI
