Retaining Ring Pliers, Internal / External, Replaceable Tips

Retaining Ring Pliers with Ratchet Lock and Tip Kit

The Model 65 pliers provides safe and stable service of large retaining rings. With its patented automatic ratchet lock and 12 point broached jaws, the 65 offers unmatched support for the most secure and stable ring installation and removal. These pliers contain the patented push-button feature which allows for easy convertibility to and from internal and external use. The automatic ratchet lock feature keeps rings open or closed for easy installation and removal. The spring return handles allow for greater tool control and ease of use. Each pliers contain 6 pairs of alloy steel color coded tips and a hex wrench within a handy tip kit pouch. These patented pliers replace eight or more of any single competitor's limited-use pliers.

ring size service SAE:

• Internal: 1-13/16inch. thru 4inch.
• External: 1-1/2inch. thru 4inch.


ring size service metric:

• Internal: 32mm thru 100mm.
• External: 31mm thru 100mm.


tip sizes SAE:

• Bent 15degrees: .090inch., .108inch., .120inch.
• Bent 90degrees: .090inch., .108inch., .120inch.


tip sizes metric:

• Bent 15degrees: 2.3mm, 2.7mm, 3.0mm.
• Bent 90degrees: 2.3mm, 2.7mm, 3.0mm.
